Dejero GateWay 200 Series

Fanless networking appliance for nomadic and mobile connectivity

Dejero GateWay 200

Dejero GateWay provides fast, reliable, and secure access to the public Internet, private networks, and SaaS providers while in nomadic or mobile situations.

Leveraging Dejero’s Smart Blending Technology, GateWay intelligently blends multiple network connections—like cellular(including FirstNet) and satellite—from multiple providers to deliver a diversified virtual network that increases available capacity and delivers greater reliability.

With a wide operating temperature range and fanless chassis, the GateWay 200 Series is designed to deliver reliable connectivity for sending and receiving voice, video, and data while in harsh nomadic or mobile environments. The appliance contains integrated modems that connect to external antennas for optimal performance and supports VPN tunneling for secure access to private networks.

Reliability-icon RELIABILITY

BUILT-IN INTELLIGENCE

The connection diversity of our Smart Blending Technology provides always-on connectivity for mission-critical applications.

Versatility-icon AVAILABILITY

AGGREGATED COVERAGE

Avoid location-based coverage gaps. Network provider diversity maximizes availability in nomadic and mobile scenarios.

Security-icon SECURITY

PEACE OF MIND

Dejero routes packets over multiple connection paths to ensure a high level of security. Establishing a VPN connection adds an additional layer.

InVehicle-Icon DURABILITY

DESIGNED FOR TRANSPORT

The ruggedized fanless design and extended operating temperature range can withstand the harsh mobile environments of public safety and transit vehicles.

PRODUCT SPECIFICATIONS

  GATEWAY 211 GATEWAY 212
NETWORK CONNECTIONS

CELLULAR Up to 3 x 3G/4G/LTE/LTE-A/FirstNet
ETHERNET 4 x 1Gb/s ports for LAN (2 x PoE)
1 x 1Gb/s port for WAN
Wi-Fi 2 x dual-band wireless (802.11 a/b/g/n/ac)
3 x 3 MIMO Technology up to 1.3 Gb/s

USER INTERFACE

INDICATORS LAN/WAN indicator LEDs
CONTROL Cloud management portal

COMPUTE

CPU x86
STORAGE 64 GB 1 TB

POWER

SUPPLY 9-36 VDC
CONSUMPTION 100W (with PoE in use)

PHYSICAL

DIMENSIONS 26.4 x 10.64 x 15.62 cm (10.4 x 3.8 x 6.1 inches)
WEIGHT 4.7 kg (10.4 lbs.)
OPERATING TEMPERATURE -20°C to 60°C (-4°F to 140°F)
CONNECTORS 5 x RJ45 (Ethernet), 6 x SMA (LTE-A), 6 x SMA-RP (WiFi), 2 x USB 2.0, 4 x USB 3.0

KEY FEATURES

ALWAYS CONNECTED

Stay connected using Dejero’s patented Smart Blending Technology that provides high reliability and bandwidth



EASY DEPLOYMENT

Wide temperature range and fanless chassis can be vehicle-mounted for tracking



PROVIDER AGNOSTIC

Aggregate multiple provider network connections to reliably to support data apps for public safety



RELIABLE CLOUD ACCESS

Access cloud-based applications without fear of losing connectivity in mobile environments



CONSOLIDATE CONNECTIVITY SERVICES

Access multiple provider networks with streamlined billing through Dejero’s connectivity services



SEND AND RECEIVE LARGE FILES

Use FTP services to transfer files to and from the central command or remote locations



REAL-TIME VIDEO

Share mission-critical dash-cam, body-cam, and drone feeds confidently with central command



VOIP COMMUNICATION

Utilize IP-based applications seamlessly



CLOUD MANAGEMENT

Dejero Control is a cloud-based management system that gives you the power and flexibility to centrally manage your Dejero equipment from a web browser.



Design, features and specifications are subject to change without notice.

Looking for a printable copy of the Dejero GateWay 200 Series product brief?

Download the product brief

ACCESSORIES

Dejero BackPack

Backpack

The backpack makes it easier for you to move around and quickly change position while covering news, sports and live events. Features include a dedicated battery compartment, expandable bottom compartment for carrying extra cables and a battery, and built-in cable management.

Dejero Engo Sling Bag

Sling Bag

The sling bag can be positioned on your hip to provide easy access to the touch screen for controlling the EnGo and monitoring the shot. Or it can slide behind you and out of the way. Features include an adjustable shoulder strap and pouch for accessories.

EnGo Vehicle Mount Kit

Vehicle Mount Kit

The Vehicle Mount Kit is an ideal solution for crews wanting versatility. The EnGo can be mounted in a vehicle and connected to rooftop antennas for increased cellular network reception or live shots while driving. And it can quickly be dismounted and placed in a backpack or sling bag, or mounted on a camera for mobility while on location. One transmitter does it all. Learn more...

GATEWAY SOLUTION DIAGRAM

GateWay Solution Diagram
